Facts and Figures
| Current Number | 4 |
|---|---|
| Railway Represented | South Brooklyn Railway |
| Builder | Brooklyn Heights |
| Built In | 1907 |
| Builder's order id | |
| Currently in (State) | Connecticut |
| --(Locality) | East Haven |
| Totally out of svc date | 1980 |
| (Initial retirement date) | |
| Car Type | locomotive |
| -subtype | box cab |
| -designation | |
| Status | stored inoperable |
| More info | http://www.bera.org/cgi-bin/viewcar.pl?car=4 |
| Gauge | 4'8.5" |
| Construction | steel |
| Roof type | AR |
| Ended | DE |
| Length | 31'0" |
| Width | |
| Height | |
| Weight | 114000 |
| #Seats | n/a |
| #Wheels/Conf. | 8 |
| Total HP | 880 |
| Trucks | Alco Z380 |
| Brakes | 14EL (K14) |
| Compressor | WABCO D3F |
| Control | WH HB [(189)] |
| Motors | WH 300 (4) |
| Voltage (if not 600DC) |
 |
Locomotive 4 on display at Branford in 2015 Trainweb photo: http://www.trainweb.org/chris/15stm2.html |
 |
Locomotive 4 in storage at Branford in 2016 Preserved Traction Blog photo: https://pnaerc.blogspot.com/2017/01/photo-gallery.html |
